CPF-100D1X
Waterman
Portable
Disinfection Machine
ISO9001, CE
Not Straight Drink
Ordinary temperatures
One year
Wall-mounted or vertical / floor-standing
Chemical Method
Water Treatment Plant (WTP), Waste Water Treatment Plant (WWTP)
Plywood Box
0-100g/h
Manual / Flow Control
Industry
220V
Chlorine Dioxide
Manual / Automatic
Waterman
220V, 50Hz
NaClO2 and HCl
Integrated structure, supports wall-mounted or vertical installation
30g/h, 50g/h, 100g/h, 200g/h, Option
PVC
Titanium alloy reactor, PVC shell
Place of Origin: Jiangsu, China (Mainland)
Model: CPF-100D1X
Certification: ISO9001, CE Marked
EINECS No. 233-162-8
CAS NO. 10049-04-4
Control Mode: Manual / linkage / Flow auto-control
Installation Method: Wall-mounted or vertical
Power Supply: 220V/50Hz
Main parameters:1. Operating voltage: AC220V plus or minus 10%2. Working temperature: -5 ~ 50 degrees Celsius3. Relative humidity: 80%4. Maximum pressure of water-pipe-line:<0.7Mpa5. There should be no strong electromagnetic field interference around the equipment.6. Function: Manual / Linkage / Flow auto-control Low liquid level alarm function Timing start / stop function
Alarm remote transfer
5 NaClO2 + 4HCl = 4ClO2 + 5NaCl + 2H2O
NaClO2: industrial sodium chlorite (purity≥78% ) or liquid
Activator: industrial first grade compound hydrochloric acid (purity≥31%) or other weak acid or strong acid
Two raw chemicals of NaClO2 and HCl are to be inhaled into the reactor proportionally by two metering pumps, in which produce quantitative high-purity ClO2 solution, and then to be dosed directly in the water tank or pressured water pipe together with the dilution water.
The highest outlet pressure of ClO2 solution is 0.40Mpa. Raw chemicals conversion rate is higher than 90%. The dosage of ClO2 can be adjusted manually or automatically by receiving 4-20mA signal sent by flow rate sensor.
